Normale cabina di verniciatura per auto

WLD7200 Normal Car Spray Booth Configurazione:

Wallboard: Sandwich style EPS (epispastics polystyrene) 50mm thickness. Galvanized steel roof panel.

Basement: Galvanized steel sheet and square steel pipe construction. 2 rows of grids with floor filter 3 rows of checkered plates. 2 pcs of ramps.

Porta: 3 pcs of luxury front doors with 0.8mm thickness colorful steel skin. Size: 3000(w) x 2750(h). 1 pc of emergency door. Watching window with aluminum frame.

Air Circulation System:2x4kw intake fan, 1x5.5kw exhaust fan. BELIMO 20N electric damper.

Burner: Italy Riello G20 diesel burner, 200000Kcal/h. The heating time 5-7min(20-60.C). Max. temperature
at 80.C. Fuel consumption is 4-5kg/vehicle.

Scambiatore di calore: Made of stainless steel. The heat exchange rate reaches 85 percent .

Lighting System:Ceiling light has 24 pcs of 16w LED lamps. 800 Lux.

Air Purification: Dual filtering structure. The primary filter can capture granules larger than 10μm. Ceiling filter capture granules bigger than 5μm. The air cleanliness in the working environment can reaches 98 percent .

Pollution Control System: Multi-layer fiberglass filter.

Disegni:
